02 2350 ... T06CB T
Field-attachable Connectors Quicklock
Quicklock plug with locking latch, IP67, size 12, straight version, with plastic housing and solder terminals
批准 ULus, CE
技术数据
环境条件
Temperature range: -40 °C/+80 °C
物料
Insulating body: PBT, V-0 according to UL94
Contact pin: CuZn, gold-plated
Housing: PBT, V-0 according to UL94 *1
Locking: Zn-alloy, chrome-plated
Cap nut: PBT, V-0 according to UL94 *2
1) outdoor sustainable (F1 according to UL 746C)
2) outdoor sustainable (F1 according to UL 746C)
机械数据
Protection class: IP67 *1
1) only in locked condition with an appropriate counterpart
可连接的电线用于焊接连接
Section: 0.34–0.75 mm²/AWG 22–20 (2–6 poles)
0.25–0.34 mm²/AWG 24–22 (7–8 poles)
Cable diameter: 4.0–5.5 mm (state of delivery)
3.0–4.5 mm (with accessory 9923 SL4,5)
5.0–6.0 mm (with accessory 9923 SL6)
电气数据（Tamb 20 °C）
Rated current: 5 A (2–6 poles)
3 A (7–8 poles)
Rated voltage: 125 V AC/DC (2–6 poles)
100 V AC/DC (7–8 poles)
Rated impulse voltage: 1500 V AC (2–6 poles)
1000 V AC (7–8 poles)
